The Remington 870 is a legendary pump-action shotgun renowned for its reliability and versatility. Designed in 1950, it remains a popular choice for home defense, hunting, and sport shooting.
History and Development
The Remington 870, introduced in 1950, is one of the most iconic pump-action shotguns ever produced. Designed by Frederick L. Rehm, it quickly gained popularity for its durability and versatility. Over 10 million units have been manufactured, making it a cornerstone of American firearms production. Initially developed for hunting and sport shooting, the 870 later became a favorite among law enforcement and military units worldwide. Its design emphasizes simplicity, with a tubular magazine and reliable pump-action mechanism. The shotgun’s success lies in its adaptability, as it can be configured for various purposes, from home defense to competitive shooting. This timeless design has solidified the Remington 870 as a legend in firearms history, earning it a reputation for dependability and performance across generations.
Key Features and Variants
The Remington 870 is celebrated for its robust design and interchangeable components, offering unparalleled adaptability. Its tubular magazine holds four to eight rounds, depending on the configuration, and the pump-action mechanism ensures reliable cycling. Key features include a smooth action, durable finish, and intuitive operation. Variants like the 870 Express, 870 Tactical, and 870 Wingmaster cater to diverse needs, from home defense to hunting. The Tactical model includes a shorter barrel and tactical rail for accessories, while the Wingmaster is designed for sport shooting with a polished finish. Additionally, the 870 is available in various gauges, including 12, 20, and 28, making it suitable for both novice and experienced shooters. Its wide range of configurations ensures that the Remington 870 can be tailored to meet specific user preferences and requirements effectively.
Assembly and Disassembly
The Remington 870 is designed for straightforward assembly and disassembly, enabling easy maintenance and customization. Users can disassemble the shotgun by removing the barrel and magazine tube, using basic tools like a screwdriver.
Step-by-Step Assembly Process
- Begin by ensuring all components are clean and free of debris.
- Attach the magazine tube to the receiver, aligning it securely.
- Install the barrel onto the receiver, ensuring it is properly seated and aligned.
- Reattach the forearm and slide, ensuring smooth operation.
- Mount the stock to the receiver using the provided screws.
- Tighten all screws firmly but avoid over-tightening.
- Perform a final inspection to ensure all parts are correctly assembled.
Always refer to the official manual for detailed instructions and safety guidelines.
Disassembly for Maintenance
Disassembling the Remington 870 is straightforward and essential for proper maintenance. Start by ensuring the shotgun is unloaded. Remove the magazine cap and unscrew the barrel from the receiver. Next, take off the forearm and slide, allowing access to the internal components. Detach the stock by removing the screws, and carefully pull it away from the receiver. The bolt and carrier can then be removed for inspection and cleaning. Be sure to note the position of each part to facilitate reassembly. Always follow the manufacturer’s instructions to avoid damage or misalignment. Regular disassembly ensures the shotgun remains in optimal working condition, preventing rust and wear.
Safety Guidelines
Always handle the Remington 870 with caution, ensuring the muzzle points away from people. Keep fingers off the trigger until ready to shoot. Verify the chamber is clear before storage or disassembly. Store ammunition separately and use proper locking devices to prevent unauthorized access. Regularly inspect the shotgun for wear or damage. Follow all local firearm safety regulations and guidelines provided in the user manual to ensure safe operation and maintenance.
Proper Handling Techniques
Proper handling of the Remington 870 begins with a firm, controlled grip. Always keep the muzzle pointed in a safe direction, away from people and valuables. Maintain finger discipline by keeping your finger off the trigger until you are ready to shoot. Ensure the shotgun is unloaded before handling or transporting it. Always verify the chamber and magazine are clear by visually inspecting and feeling for any obstructions. When shooting, stand with a stable stance and keep the buttstock firmly against your shoulder. Avoid overreaching or using improper leverage, as this can affect control. Always wear appropriate eye and ear protection when firing. By following these techniques, you can minimize risks and ensure safe, effective operation of the Remington 870.
Storage and Safety Precautions
Proper storage of the Remington 870 is essential for safety and longevity. Always store the shotgun unloaded, with the action open, and separately from ammunition. Use a secure location, such as a locked cabinet or gun safe, to prevent unauthorized access. Consider using a trigger lock or other safety devices for added security. Before storage, clean and lubricate the firearm to prevent rust or corrosion. Store in a dry, cool environment away from humidity and extreme temperatures. Never leave the shotgun in a vehicle or other unsecured location. Always ensure the firearm is unloaded before storage, and double-check the chamber and magazine tube visually and by feel. Proper storage practices help prevent accidents and maintain the integrity of your Remington 870.
Cleaning and Maintenance
Regular cleaning and maintenance are crucial for the Remington 870’s performance and longevity. Always disassemble the shotgun and clean the barrel, chamber, and action with appropriate solvents and brushes. Lubricate moving parts to ensure smooth operation and prevent corrosion. Follow the manufacturer’s guidelines for recommended cleaning frequencies and products. Proper care ensures reliability and extends the shotgun’s service life.
Routine Cleaning Procedures
Routine Cleaning Procedures
Regular cleaning is essential to maintain the Remington 870’s performance and reliability. Start by disassembling the shotgun, removing the barrel, magazine tube, and action bars. Use a soft brush and solvent to clean the barrel, chamber, and magazine tube, ensuring all residue is removed. Wipe down the receiver and action with a clean, lightly oiled cloth. Lubricate moving parts, such as the action bars and pump, with a high-quality firearm lubricant. Inspect all components for wear or damage and replace as needed. Use a bore brush to thoroughly clean the barrel’s interior. After cleaning, reassemble the shotgun and apply a thin layer of rust-inhibiting oil to protect metal surfaces. Always follow the manufacturer’s instructions for cleaning products and procedures to ensure optimal functionality. Cleaning should be done after every use or heavy firing schedule.
Addressing Common Issues
The Remington 870, like any firearm, may encounter issues over time. Common problems include failure to eject, feeding issues, and wear on the action bars. To address these, inspect the chamber and magazine tube for residue buildup, as this can cause malfunctions. Clean these areas thoroughly with a solvent and brush. If shells fail to feed properly, check the magazine spring for damage or compression loss and replace it if necessary. Worn-out parts, such as the ejector or extractor, may need replacement. Lubricate the action bars and pump regularly to ensure smooth operation. For persistent issues, consult the user manual or contact Remington customer support. Always use high-quality ammunition to minimize potential problems. Regular maintenance and inspection can prevent many of these issues from arising. Addressing these common concerns will keep your Remington 870 functioning reliably for years.
Accessories and Upgrades
Enhance your Remington 870 with accessories like tactical stocks, scopes, and magazine extensions. Upgrades such as improved triggers and barrels can optimize performance for specific uses.
Popular Accessories
Popular accessories for the Remington 870 include tactical stocks, scopes, magazine extensions, and flashlight mounts. These upgrades enhance functionality for home defense, hunting, or sport shooting. Tactical stocks improve control, while scopes aid accuracy. Magazine extensions increase ammo capacity, and flashlight mounts provide visibility in low-light conditions. Slings and choke tubes are also widely used, offering versatility for different shooting scenarios. These accessories are designed to optimize performance and adapt the shotgun to individual preferences, ensuring reliability and effectiveness in various applications.
Installation and Configuration Tips
Installing accessories on the Remington 870 requires careful attention to ensure proper fit and function. Start by disassembling the shotgun as per the manual, ensuring all components are secure. For upgrades like tactical stocks or magazine extensions, align the parts precisely and tighten firmly. When installing optics, use a torque wrench to avoid over-tightening. Mount flashlight or laser sights securely, ensuring they don’t obstruct the sight plane. Always follow the manufacturer’s instructions for specific accessories. Test the configuration at the range to ensure reliability. Regularly inspect all modifications for wear or looseness. Proper installation enhances performance and reliability, making the Remington 870 adaptable to various shooting needs. If unsure, consult a professional gunsmith to avoid potential issues.
